Product Details
Peerless’ first compression driver, the DFM-2535R00-08, delivers incredibly smooth response from 1,500 to 17,000 Hz thanks to its unique 1.4″ damped titanium diaphragm with polyimide surround. This driver has a 1″ exit with a standard 2 or 4-bolt mount. All of the materials resist environmental factors of heat, vibration, and aging, which ensures many years of stable performance. The Tymphany DFM-2535R00-08 HF driver is a great choice for use in pro-quality 2-way and 3-way sound reinforcement speaker systems, as well as high efficiency home and automotive audio playback applications.
Specifications: • Power handling: 30 watts RMS/60 watts program (with recommended 1,500 Hz, 12 dB/octave crossover) • Fs: 745 • VCdia: 1.4″ • Throat diameter: 1″ • Impedance: 8 ohms • Frequency response: 1,500-15,000 Hz • SPL: 107.7 dB 2.83V/1m • Dimensions: Overall diameter: 3.5″, Depth: 2″.
Product Specifications
- Mounting Type –Â 4-Bolt
- Exit Diameter –Â 1″
- Diaphragm Material –Â Titanium
- Impedance –Â 8 ohms
- Power Handling (RMS) –Â 30 Watts
- Brand –Â Peerless by Tymphany
- Model –Â DFM-2535R00-08
- Part Number –Â 264-1420
- UPC –Â 848864017143
- Unit of Measure –Â EA
- Weight –Â 2.2500 lbs.
