PEERLESS BY TYMPHANY 1¼” TETORON DOME TWEETER OPEN
| Description | Peerless 1¼” Fabric Dome Tweeter 8 ohm |
|---|---|
| Cms | 0.092mm/N |
| Coil | 32.4mmØ |
| Depth | 21.7mm |
| Diam. | ~80mmØ |
| Fs | 750Hz |
| Hole | 42mmØ |
| Hole Cutout | 42mmØ |
| Impedance | 8Ω Re 6.5Ω |
| Impedance (Ohm) | 8 ohm |
| Inch | 1.25 |
| Le | 0.065mH |
| Manufacturer | Peerless |
| Mms | 0.488g |
| Power | 15Wrms |
| Power (RMS) | 0-50 Watt |
| Price Type | each |
| Prms | 15W |
| Qes | 1.46 |
| Qms | 4.61 |
| Qts | 1.1 |
| QTY | 1 |
| Re | 6.5Ω |
| Sd | 11cm² |
| Sens. | 89.2dB |
| Series | Peerless Dome Tweeter |
| Size | 1.25′ |
| Type | Tweeter |
| Vas | 0.016L |
| Width | 80mmØ |
| Zn | 8ΩOX32SC00-08 Rev1 MP1 – Product Sheet – OX32SC00-08.Rev1.MP1 – Product Sheet (6) |
Description
MADE WITH HIGH STRENGTH TETERON DIAPHRAGM
- This compact 32mm transducer is engineered with a powerful neodymium motor and smooth Teteron diaphragm delivers crystal-clear audio across a broad range. Weighing 96.6g, it suits high-end designs where space is tight and expectations are high. For premium headphones or custom speakers, the OX32SC00-08 offers effortless integration, low resonance, and uncompromising sound quality.
- 1¼” Teteron dome.
- Compact and powerful neodymium motor.
- Low resonance.
- At just 96.6g, making it easy to integrate into portable or compact speaker systems.
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 16 × 16 × 16 cm |
